Connecting of peripherals requires the use of grounded shielded cables. The only difference is that the color model is shipped with the color kit, and the monochrome model can be upgraded with the color kit, which has to be ordered separately. Close the machine upper cover. If the driver voltage is higher than specified For full details see the appropriate section in the User’s Guide. When the resistor heats up, the ink touching it evaporates. The figure below shows the pin Cannon connector used to connect the serial interface, indicating the transmission signals.
||23 October 2009
||Windows NT/2000/XP/2003/2003/7/8/10 MacOS 10/X
||Free* [*Free Regsitration Required]
This phenomena determines the formation of a bubble which quickly expands and compresses the remaining liquid inside the nozzle.
If the print quality should deteriorate along the writing line, it is advisable to check the distance and if necessary, adjust the gap between the print head and printing surface. Detailed instructions for the installation are supplied in the package with the device.
DECwriter 500i DECcolorwriter 520ic Spare Parts & Options List
Check that the interface cable is the correct type and that it is not too long 2. Switch the printer off before inserting a card. Always switch off the printer before switching off the computer.
Jamming or irregular feed may be caused by paper residue or foreign bodies along the paper path or by an incorrect calibration of the tension of the paper motor belt.
Black print head 3. Furthermore it should be remembered decwritee an excessive increase in the environmental temperature could cause smeared printing or irregular bubble formation. For faults found, see the diagnostics guide section 5. The lever is only to be moved when the print head is in cartridge change position.
HP Deskjet ; color inks cartridge: The lever is usually directed towards the operator BLACK settingand in this position 500ii printed is equipped with a black ink head. The last of these three lines must not have any white lines in the colored bands.
Decwriger, replace the main board.
Printer: DEC DECWriter i | OpenPrinting – The Linux Foundation
The printable area for continuous modules can be obtained from the table below, together with the figure that illustrates the meaning of the values in the table. Detailed instructions are contained in the packing together with the device.
Some paragraphs are marked on a dark background and advise the use of particularly important situations or procedures.
User Maintenance Black Ink jet head cleaning and maintenance: If the printer does not initialize enabled at each power-on and clears the printer and all the LEDs are blinking, check that the paper is not jammed, disconnect the printer from the system and take out the memory card. The miniresistors are positioned to correspond to the nozzles and are connected electrically with the head external contacts.
If the fault persists replace the print carriage and flat cable, and finally the main board If the printout is smeared or irregular, ensure that the carriage movement is smooth, the carriage belt tension device works correctly, the encoder strip is clean and check the setting of the driver voltage.
DECwriter i DECcolorwriter ic Spare Parts & Options List – Manx
The user is responsible for the ink reset operation when one or more nozzles are clogged. If there are, switch off the printer then run a new print test. Diagnostics and Test 5.
For full details see the appropriate section in the User’s Guide.
Diagnostics ddecwriter Test – Print quality faults Includes all faults which do not block the printer but reduce the print quality considerably. To do so, grasp the head pulling it towards the rear and remove it from recwriter position. They are placed in sequence on each column as illustrated in figure Refer to this manual when a fault has not been corrected using the recommendations described in the Installation and User Guide included with the printer.
Push the slide back and forth as shown in the figure, until some ink is seen one or decwriteg centimeters in the tube below the slide. The chapters are organized to develop an autonomous and gradual approach to printer problems. If the paper feed from the drawer is irregular, re-shuffle and turn over the sheets in the drawer, clean the feed rollers, adjust the side clasps and the rear sheet clasp.
The figure below shows the pin Cannon connector used to connect the serial interface, indicating the transmission signals. The sprocket can be used for continuous paper feed or for single sheets. The card features and corresponding installation procedures are described in the appropriate manual, included in the same 500l as the memory card.
